Description

System

Processor: STM32WB55RG, ARM Cortex-M4
Bluetooth Low Energy 5.4
Battery: 2100 mAh (up to 28 days)
Display: LCD Monochrome 128×64 px
MicroSD: up to 256 GB (SPI mode)
NFC

Read NFC cards
Save to SD card
Write (only rewritable cards)
Emulate:

NXP MIFARE Classic®, Ultralight®, DESFire®, etc.
FeliCa™
HID iClass (PicoPass™)
NFC Forum protocols

Sub-1 GHz module

Supported frequencies: 315-900 MHz
Read & decode signals
Save to SD card
Analyze unknown signals (Read RAW)
Generate new remotes
Infrared

Read infrared signals
Save to SD card
Emulate infrared signals
Built-in signal library
Guess signals for TV and AC
Supported protocols:

NEC family
Kaseikyo
RCA
RC5, RC6
Samsung
SIRC

RFID

Frequency: 125 kHz
Modulation: AM/OOK
Coding: ASK, PSK
Supported cards:

EM400x, EM410x, EM420x
HID
Indala
FDX (A & B)
Pyramid
AWID
Viking
Jablotron
Paradox
PAC Stanley
Keri
Gallagher
NexWatch

iButton 1-Wire

Read 1-Wire keys
Save to SD card
Write (only rewritable keys)
Emulate 1-Wire keys
Supported protocols:

Dallas DS199x, DS1971
CYFRAL
Metakom
TM2004
RW1990

Size

Width: 100 mm
Height: 40 mm
Depth: 25 mm
Weight: 102 g (3.6 oz)
